4. FRONT PANEL ASSY
(1) Removethescrews.
(2) Cutthewireclampband,thendisconnecttheconnectorwiresandtheFFCCable.
SIDE PANEL
TOP COVER
→
DOOR
→ →
FRONT PANEL ASSY
Proceeding :
View from bottom
Direction of photograph: D
cut
CN21
CN44
CN41
