Denon RCD-N7 Service Manual

105
Ref. No. Part No. Part Name Remarks Q'ty New
L101,102 nsp
BEAD , FERRITE
(FCM2012KF-121T08 , 120 OHM)
CLZ9R010Z
L104-107 nsp
BEAD , FERRITE
(FCM2012KF-121T08 , 120 OHM)
CLZ9R010Z
L201 nsp INDUCTOR CHIP 10UH (3225 PKG) HLQ10E100KRZ
L301 nsp FERRITE , CHIP BEAD(220ohm, 2012) CLZ9R006Z
L303,304 nsp
BEAD , FERRITE
(FCM2012KF-121T08 , 120 OHM)
CLZ9R010Z
L401,402 nsp
BEAD , FERRITE
(FCM2012KF-121T08 , 120 OHM)
CLZ9R010Z
L406 nsp
BEAD , FERRITE
(FCM2012KF-121T08 , 120 OHM)
CLZ9R010Z
L501 nsp
BEAD , FERRITE
(FCM2012KF-121T08 , 120 OHM)
CLZ9R010Z
L601 nsp
BEAD , FERRITE
(FCM2012KF-121T08 , 120 OHM)
CLZ9R010Z
L603-605 nsp
BEAD , FERRITE
(FCM2012KF-121T08 , 120 OHM)
CLZ9R010Z
L701,702 nsp COIL , SPEAKER (10UH/7A) CLZ9Z116Z *
L705-712 nsp
BEAD , FERRITE
(FCM2012KF-121T08 , 120 OHM)
CLZ9R010Z
L723,724 nsp CHIP , BEAD HLZ9Z014Z
L727,728 nsp CHIP , BEAD HLZ9Z014Z
L751,752 nsp COIL , SPEAKER (10UH/7A) CLZ9Z116Z *
WN24 nsp WAFER , CD MECHA CJP16GA117ZY
X201 943141001190S CRYSTAL, 16.934MHz, HC-49/SMD, 12pF, 25PPM COX16934E120S
X202 943142011280S 16M Resonator
COXCSTCE16M0V51
X401 90M-JX001070R CRYSTAL, 12.288MHz, HC-49/S, 32pF, 50PPM HOX12288E320C
X501 943141003490S CRYSTAL, 13.500MHz, HC-49/SMD, 16pF, 30PPM COX13500E160S
nsp HEAT SINK CMY1A368 1 *

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
