Denon RCD-N7 Service Manual

104
Ref. No. Part No. Part Name Remarks Q'ty New
C766 00MDK56333300 CAP , CHIP(2012, 33nF/50V) CCUC1H333KC
C767 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C768 943134003040S CAP , ELECT CCET1HKLH332KK8
C769 00D2544692901 CAP , ELECT(ELNA, RFO, 63V/10U) CCEA1JRFO100T
C781,782 00MDD95331300 CAP , CHIP CCUC1H331JA
C783 nsp CAP , METALIZED FILM(100V/0.47UF, 5%) CCME2A474JR08T
C784,785 943132003110S CAP , CHIP (2012, 100V/0.1uF) CCUC2A104KC
C786,787 943132003100S CAP , CHIP (2012, 100V/0.01uF) CCUC2A103KC
C790 nsp CAP , METALIZED FILM(100V/0.47UF, 5%) E2 CCME2A474JR08T
C797,798 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C891-893 nsp RES , CHIP(0 OHM , 5% , 1608) CRJ10DJ0R0T
C900,901 nsp CAP , ELECT CCEA1HH100T
C902,903 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C991 nsp CAP , ELECT CCEA1CH100T
C992 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C993 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C994 nsp CAP , ELECT CCEA1CH100T
C995,996 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
RESISTORS GROUP
R111,112 nsp RES , METAL OXIDE FILM KRG1SANJ222RT
R115 nsp RES , METAL OXIDE FILM KRG1SANJ222RT
R429 nsp RES , CHIP 1% CRJ10DF1202T
R565 nsp FERRITE , CHIP BEAD(220ohm, 2012) CLZ9R006Z
R569 nsp FERRITE , CHIP BEAD(220ohm, 2012) CLZ9R006Z
R575 nsp FERRITE , CHIP BEAD(220ohm, 2012) CLZ9R006Z
R579 nsp FERRITE , CHIP BEAD(220ohm, 2012) CLZ9R006Z
R700 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
R709,710 943124003380S RES , CHIP , 18 OHM, 1% , 1/8W , 2012 CRJ18AF18R0T
R711,712 943124003360S RES , CHIP , 3.3 OHM, 1% , 1/8W , 2012 CRJ18AF3R30T
R718,719 nsp RES , METAL OXIDE FILM KRG1SANJ222RT
R722 nsp RES , METAL OXIDE FILM KRG1SANJ222RT
R759,760 943124003380S RES , CHIP , 18 OHM, 1% , 1/8W , 2012 CRJ18AF18R0T
R761,762 943124003360S
RES , CHIP , 3.3 OHM, 1% , 1/8W , 2012 CRJ18AF3R30T
R997 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
R998 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
R999 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
OTHER PATRS GROUP
BK51 nsp BRACKET , PCB CMD1A569
BN62 nsp WIRE ASS'Y (8P, 2MM, 250MM) CWB1C008250NG
CN24 nsp WAFER CJP11GA117ZY
CN25 nsp WAFER , STRAIGHT(DVD LOADER) CJP06GA19ZY
CN26 nsp WAFER , STRAIGHT CJP05GA19ZY
CN31 nsp WAFER(11P, ST 1.25MM) CJP11GA115ZY
CN41 nsp WAFER, STRSIGHT, 1MM, SMD CJP30GA193ZY
CN42 nsp WAFER , CARD CABLE (SMD, 1MM) CJP23GA193ZY
CN43,44 nsp LOCKING TYPE , STRAIGHT WAFER , 2MM CJP07GI236ZW
CN45 nsp LOCKING TYPE , STRAIGHT WAFER , 2MM CJP13GI236ZW
CN61 nsp LOCKING TYPE , STRAIGHT WAFER , 2.5MM CJP05GI237ZW
ET51 nsp PALTE , EARTH HJT1A025
ET61 nsp PALTE , EARTH HJT1A025
ET71,72 nsp PALTE , EARTH HJT1A025
ET81 nsp PALTE , EARTH HJT1A025
JK51 943643002710S JACK , BOARD CJJ4M046Z
JK63 90M-YT004010R TERMINAL , IN/OUT CJJ4R019W
JK64 262010004005S MODULE , OPTICAL (RX,3.3V) HJSTORX147L
JK71 943646011730S TERMINAL , SPEAKER (2P, RED BLACK) CJJ5N016Z *
JK72 943646011740S TERMINAL , SPEAKER (2P, BLACK, RED) CJJ5N017Z *

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
