Denon RCD-N7 Service Manual

103
Ref. No. Part No. Part Name Remarks Q'ty New
C597 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C601 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C602 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C603 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C604 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C605 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C606 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C607,608 nsp CAP , ELECT CCEA1EH221T
C656 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C658 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C661 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C662 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C663 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C664 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C665 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C666 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C667 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C680 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C681 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C682 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C683 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C684 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C685 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C686 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C687 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C688 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C689 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C690 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C691 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C692 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C693 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C694 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C695 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C696 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C697 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C698 nsp CAP , CHIP (1608, 50V/0.01uF) CCUS1H103KC
C699 nsp CAP , CHIP (1608, 50V/1000pF) CCUS1H102KC
C700 nsp RES , CHIP(0 OHM , 5% , 1608) CRJ10DJ0R0T
C701-703 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C704 nsp CAP , ELECT CCEA1CH101T
C705,706 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C707 nsp CAP , ELECT CCEA1HH100T
C708 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C709 00MDK56333300 CAP , CHIP(2012, 33nF/50V) CCUC1H333KC
C710,711 943132003120S CAP , CHIP (3216, 100V/0.1uF) CCUP2A104KC
C712,713 00MDK56333300 CAP , CHIP(2012, 33nF/50V) CCUC1H333KC
C714,715 943132003120S CAP , CHIP (3216, 100V/0.1uF) CCUP2A104KC
C716 00MDK56333300 CAP , CHIP(2012, 33nF/50V) CCUC1H333KC
C717 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C718 943134003040S CAP , ELECT CCET1HKLH332KK8
C719 00D2544692901 CAP , ELECT(ELNA, RFO, 63V/10U) CCEA1JRFO100T
C724-726 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C728,729 nsp RES , CHIP(0 OHM , 5% , 1608) CRJ10DJ0R0T
C731,732 00MDD95331300 CAP , CHIP CCUC1H331JA
C733 nsp CAP , METALIZED FILM(100V/0.47UF, 5%) CCME2A474JR08T
C734,735 943132003110S CAP , CHIP (2012, 100V/0.1uF) CCUC2A104KC
C736,737 943132003100S CAP , CHIP (2012, 100V/0.01uF) CCUC2A103KC
C745,746 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C751-753 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C754 nsp CAP , ELECT CCEA1CH101T
C755,756 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C757 nsp CAP , ELECT CCEA1HH100T
C758 nsp CAP , CHIP (1608, 50V/0.1uF) CCUS1H104KC
C759 00MDK56333300 CAP , CHIP(2012, 33nF/50V) CCUC1H333KC
C760,761 943132003120S CAP , CHIP (3216, 100V/0.1uF) CCUP2A104KC
C762,763 00MDK56333300
CAP , CHIP(2012, 33nF/50V) CCUC1H333KC
C764,765 943132003120S CAP , CHIP (3216, 100V/0.1uF) CCUP2A104KC

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
