Denon RCD-N7 - Page 68

68
Ref. No. Part No. Part Name Remarks Q'ty New
P27 nsp COVER, SHIELD CMX1A294 1
P28 nsp RUBBER CHG1A113 1
P29 nsp PEF 5X8 CHG1A490 2
P30 nsp RUBBER CHG1A491 2
P31 943454100020D FIXING, BOARD CMH1A323 1 *
d
P32 943432100020D HIMELON, TAPE CHS1A032 1 *
d
C1 nsp DISPLAY PCB ASS'Y COP12347B 1
C2 nsp MAIN PCB ASS'Y E2,E1C COP12316F 1
g
C2 nsp MAIN PCB ASS'Y E3 COP12316E 1
z
C3 nsp SMPS PCB ASS'Y E2,E1C COP12319E 1
g
z
C3 nsp SMPS PCB ASS'Y E3 COP12319G 1
C4 943183009250S MODULE , TUNER (EUR) E2,E1C CNVMT104MS1-80A 1
g
C4 943183011920D MODULE , TUNER (USA) E3 CNVMT004MS0-80 1
C5 8U6321011200D IPOD DOCK CON UNIT CUP12347Z 1
C6 8U6321000200S ETHERNET PCB ASS'Y COP12348B 1
f
C7 8R1821000100S WLAN MODULE CNVCR870-2G 1
C8 943302009630S
MECHANISM ASS'Y
(CJDL2130BZ)
CJDL2130BZ 1
s
C9 943179011170S OLED MODULE CFLMXS4003-A 1
C10 nsp SUPPORT PCB ASS'Y - 2
C11 nsp PLUG, WIFI ANT ASS'Y - 1
SCREWS
S1 nsp SCREWS CTB3+6JR 28
S2 nsp SCREWS CTB3+8JR
14
g
S3 nsp SCREWS CTB3+10JR 21
g
S4 nsp SCREWS CTB3+6FFZR 10
S5 nsp SCREWS CTB3+8JFZR 2
S6 nsp SCREWS CTB3+10JFZ 7
S7 nsp SCREWS CTB26+8JFR 3
S8 nsp SCREWS CTS3+8JR 6
S9 nsp SCREWS CTW3+8JR 12
g
S10 nsp SCREWS CTW3+12JR 3
WIRES
★
101 943606011980S CABLE , CARD(1.0MM, 23P, 150MM, B TYPE) CWC4F4A23A120B08 1 *
★
102 943606011340S CABLE , CARD(1.25MM, 11P, 80MM, B TYPE) CWC4F4A11B080B08 1
