Denon RCD-N7 Service Manual

73
PinNo PinName PortName
PU/
PD
I/O STBY
Network
STBY
Note
62 P53/BCLK NC - O O/L O/L NC
63
P52/RD CHECK-4 PD I I I NC
64
P51/(WR1)/BC1 SRAMSTB PU O O/L O/L Control for TC94A92FG SRAMSTB
65
P50/(WR0)/WR/CE CE_M PD I I I Rewrite boot program start : H input set
66 P127 CCE PU O O/L O/L Chip Enable for CD DSP
67 P126 BUCK PU O O/L O/L BUS Clock for CD DSP
68 P125 NC - O O/L O/L NC
69
P47/CS0/(A23) BUS3 PU O O/L O/L BUS3 for CD DSP
70
P46/(CS1)/A22 BUS2 PU O O/L O/L BUS2 for CD DSP
71
P45/(CS2)/A21 BUS1 PU O O/L O/L BUS1 for CD DSP
72
P44/(CS3)/A20 BUS0 PU O O/L O/L BUS0 for CD DSP
73 P43/A19 OPSW PU I I I Open SW from CD Mecha
74 VCC VCC - - - - +3V
75 P42/A18 CLSW PU I I I Close SW from CD Mecha
76 VSS VSS - - - - GND
77 P41/A17 INSW PU I I I Limit SW from CD Mecha
78 P40/A16 DECRST PU O O/L O/L Reset for TC94A92FG
79 P37/A15 DREQ - I I I TC94A92FG DREQ
80 P36/A14 SBSY PU I I I CD Monitor3 (Default: SBSY) from TC94A92FG
81 P35/A13 DRVMUTE PD O O/L O/L Motor stanby
82 P34/A12 OPEN - O O/L O/L Tray Open
83 P33/A11 CLOSE - O O/L O/L Tray Close
84 P32/A10 MX_DETECT PU I I I M-XPort Detection
85 P31/A9 /H/P_ON PU O O/L O/L TAS5508 Headphone in/out selector
86 P124 /PDN_5508 PD I I I TAS5508 Power down
87 P123 /5508_MUTE PD O O/L O/L TAS5508 Soft mute of outputs
88 P122/(RXD6) E2PROMSCL PU I/O
I I Serial Clock for EEPROM (Default:O/L)
89 P121/(CLK6) E2PROMSDA PU I/O I I Serial Data for EEPROM (Default:O/L)
90 P120/(TXD6) /F_MUTE PD O O/L O/L TAS5508 Soft mute of outputs
91 VCC VCC - - - - +3V
92 P30/A8 5508_SCL PU I/O I I I2C serial Clock for TAS5508
93 VSS VSS - - - - GND
94 P27/A7 5508_SDA PU I/O I I I2C serial data for TAS5508
95 P26/A6 /RESET_5508 PD O O/L O/L System Reset for TAS5508
96 P25/A5 NC - O O/L O/L NC
97 P24/A4 NC - O O/L O/L NC
98 P23/A3 NC - O O/L O/L NC
99 P22/A2 4683_VOUT - I I I AK4683 VOUT Monitor
100 P21/A1 4683_I2C_CONT GND I O/L O/L AK4683 Communication format Select
101 P20/A0 5VCPU_ON/ /OFF PD O O/H O/H 5V Control
102 P17/D15 /4683_RESET PD O O/L O/L AK4683 Reset Signal
103 P16/D14 4683_CDTO - I I I AK4683 SCI Data Input
104 P15/D13 4683_INT - I I I AK4683 Request Signal
105 P14/D12 4683_CDTI
- O O/L O/L AK4683 SCI Data Output
106 P13/D11 4683_CCLK - O O/L O/L AK4683 SCI Clock
107 P12/D10 4683_CSN - O O/L O/L AK4683 Chip Enable Signal
108 P11/D9 /5142_SD PU I I I TAS5508 Shutdown signal
109 P10/D8 DC_PROTECT1 PU I I I Power Protection Detect for USB
110 P07/D7 NC - O O/L O/L NC
111 P06/D6 NC - O O/L O/L NC
112 P05/D5 NC - O O/L O/L NC
113 P04/D4 IPOD_DET PU I I I iPod Detect (RCD-N7)
114 P114 SW_DOWN PU I I I SW LEVEL Detect
115 P113 AMUTE PD O O/L O/L AUX/SW MUTE
116 P112/(RXD8) MX_MUTE PD O O/L O/L NC
117 P111/ DAB-P_CONT PD O O/L O/L Power Control for DAB
118 P110/(TXD8) T.MUTE PD O O/L O/L Mute for TUNER
119 P03/D3 TUNED PU I I I Tuned
120 P02/D2 TU_POWER PD O O/L O/L Power Control for TUNER
121 P01/D1 RDS_DATA PD I I I RDS DATA for Eur Version
122
P00/D0 USB_P.CONT PD O O/L O/L USB Power Control
123 P157 DC_PROTECT2 PU I I I Power Down Detect
124 P156 E_POWER_CONT PD O O/L O/H Power Control for DM870/860
125 P155/RXD6 VBUS_MONI PD O O/L O/L USB Data Output Enable (RCD-N7)
126 P154/TXD6 /E_SPICS PU O O/L O/L DM870/860 SCI Chip Select
127 P153 /E_RESET PU O O/L O/H DM870/860 Reset

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
