0044-0391-0M Rev F y solo Series Owner’s Manual
10
Desk or Table Mounting the solo-RI Display, Cont.
3. Next, locate the four (4) slots in the back of the display. Refer to Figure No. 11.
4. Referring to Figure No. 12, align and insert the tabs on the bracket with the slots in the
display back and press together until the bracket locks to the back of the display.
CARPET FEET INSTALLATION
If you are using your solo Series Digital Clinical Scale on a carpet, we recommend that you
use the included carpet feet. To install the carpet feet, perform the following steps:
1. Remove the four (4) carpet feet from the packaging.
2. Align the prongs of one carpet foot with the holes in one of the scale's existing feet.
3. Insert the carpet foot prongs into the holes, making sure the prongs align straight up and
down with the holes of the scale foot.
4. Being careful not to twist the carpet foot, with even pressure, gently push straight down
on the carpet foot to seat it into the scale foot.
5. Repeat steps 2 through 4 for the other three (3) scale feet.
Figure No. 12
(Align Tabs
with Slots in
Display back)
Display
Wall
Bracket “A”
with Feet
Installed
Tab
Figure No. 11
(Locate Slots in
Display back)
Slot
To Next Page
