0044-0391-0M Rev F y solo Series Owner’s Manual
30
PARTS IDENTIFICATION
Scale Assembly
Item Qty. Part Number Description
1 1 7100-0218 CARPET FOOT
2 1 7100-0219 FOOT
3 2 7100-0227 LEFT COVER FOR LOAD CELL
4 2 7100-0228 RIGHT COVER FOR LOAD CELL
5 1 7100-0222 COLUMN BASE COVER
6 1 7100-0221 FRICTION SLIDER
7 1 7100-0224 SLIDER ASSEMBLY FOR SPOON
8 1 7100-0223 SPOON
9 1 7100-0225 HEIGHT ROD TOP COVER
10 1 7100-0226 COLLAR FOR HEIGHT ROD
11 1 7100-0213 COVER FOR USB PORT
12 1 7100-0214 COVER FOR BATTERIES
13 1 7100-0215 BLACK MAT WITH ADHESIVE BACKING
14 1 7100-0216 PLATFORM TOP ENCLOSURE
2, 3, 15, 16,
17, 18, 19,
20, 21, 22,
35, 36
1 7100-0217
SCALE BASE BOTTOM
ENCLOSURE ASSEMBLY
23 1 7100-0211 DIGITAL INDICATOR
24 1 7100-0210 KEYPAD OVERLAY
25 1 7100-0212 CABLE TO INDICATOR
26, 27,
28, 29
1 7100-0220 WHEEL KIT
30 1 7100-0229 INDICATOR MOUNTING BRACKET
31 1 7100-0254 COLUMN, UPPER SECTION
32 1 7100-0256 COLUMN, CONNECTOR
33 1 7100-0255 COLUMN, LOWER SECTION
34 2 7100-0272 PLASTIC COVER
