0044-0391-0M Rev F y solo Series Owner’s Manual
1
INTRODUCTION
Thank you for purchasing our Detecto solo Series Digital Clinical Scale. Your scale has been
designed for simple and straightforward use and to assure accuracy and dependability for
years to come.
This manual is provided to guide you through the assembly and operation of your scale.
Please read it thoroughly before attempting to assemble or operate your scale and keep it
available for future reference.
This manual is for use with the following solo Series Digital Clinical Scales:
solo, solo-AC, solo-ACEU, solo-ACUK, and solo-RI
SPECIFICATIONS
Capacity: .…….…..…..……….. 550 lb x 0.2 lb (250 kg x 0.1 kg)
Minimum Weighing: ………..… 11 lb (5 kg)
Weight Units: .......…………..... Pounds or Kilograms (selectable)
Power Requirements: .…....…. Six (6) AA-size Alkaline batteries (included) OR an
optional medical device 9V AC/DC wall plug-in adapter
(Detecto part number PD-ACKIT, includes UK plug,
EU plug and USA plug).
Display: .....………..…….....….. Five-digit, seven-segment, 1.0-inch (25 mm) high LCD
Operation Temperature: .…….. 50 to 104 ºF (+10 to +40 ºC)
Function Keys: .....…...……….. On/Off, Zero, BMI Height, Enter, Lock/Release, Print,
Up Arrow/Mother and Baby, and Down Arrow
Annunciators: …………………. ZERO, LOCK, STA, HOLD, LB, KG, CM, FT/IN, HEIGHT,
WEIGHT, BMI, AM, PM
Interface: ……………..……….. USB (ASCII Protocol)
Dimensions:
Eye-Level Physician ..............
14.2 in W x 19.4 in D x 52.1 in H
(36.0 cm W x 49.3 cm D x 132.4 cm H)
Height Rod Units: …..………… Inch or cm
Height Rod Range: …………… 30 to 84.5 inches (76 to 214.5 cm)
Dimensions: solo-RI
Base ......................................
Remote Display ………..…....
(with mounting bracket)
14.2 in W x 15.8 in D x 2.4 in H
(36.0 cm W x 40.2 cm D x 6.1 cm H)
7.8 in W x 5.1 in D x 3.0 in H
(19.8 cm W x 12.9 cm D x 7.7 cm H)
Weight:
Eye-Level Physician …….…..
solo-RI …………..…..……….
18.9 lb (8.6 kg)
11.1 lb (5.0 kg)
