2
Precautions
2-10 D 1650iD/D 2050iD
6 Side Cover Opened when clearing paper misfeeds.
7 Power Switch Used to turn the machine on and off. (p. 2-20)
8 Parallel Interface
Connector
Used for connecting a parallel cable from the computer.
9 RJ45 Connector for
Networking
Used for connecting the network cable when this
machine is used for Internet faxing and network
scanning.
10 Printer USB Connector Used for connecting a USB cable from the computer.
11 Document Scales Used to align the document.
(p. 3-9)
12 Original Cover (optional) Presses down on the document positioned on the
Original Glass.
13 Original Glass When manually feeding a document, position it on the
Original Glass so that it can be scanned.
Position the document face down on the glass. (p. 3-9)
14 Control Panel Used to start copying or to make various settings.
(p. 2-16)
No. Part Name Description
To Next Page
