D 1650iD/D 2050iD IVZ-5
8 Error Messages
8.1 When the Message “TONER EMPTY” Appears..........................8-1
To replace the toner bottle..........................................................8-2
8.2 When the Message “PAPER JAM” Appears...............................8-4
To clear a paper misfeed in the Duplex Unit ..............................8-4
To clear a paper misfeed in the main unit or 1st Tray ................8-5
To clear a paper misfeed in the Paper Feed Unit.......................8-8
To clear a paper misfeed in the Multiple Bypass........................8-9
8.3 When the Message “ORIGINAL DOC.JAM” Appears...............8-11
To clear a misfeed in the Automatic Document Feeder
(AF-12) .....................................................................................8-11
To clear a misfeed in the Duplexing Document Feeder
(AFR-19)...................................................................................8-13
8.4 Main Error Messages and Their Remedies...............................8-15
9 Troubleshooting
9.1 When Incorrect Copies Are Produced ........................................9-1
9.2 When Copying Is Not Performed Correctly ................................9-3
10 Appendix
10.1 Specifications..............................................................................10-1
Main Unit D 1650iD/D 2050iD ..................................................10-1
Duplexing Document Feeder AFR-19 ......................................10-2
Mixed Width Document Sizes (AFR-19)...................................10-3
Automatic Document Feeder AF-12.........................................10-3
Paper Feed Unit PF-126...........................................................10-4
Shifting Unit OT-103.................................................................10-4
Job Separator JS-204...............................................................10-4
Multiple Bypass MB-6...............................................................10-5
10.2 Care of the Machine....................................................................10-6
Cleaning ...................................................................................10-6
Housing ....................................................................................10-6
Original Glass...........................................................................10-6
Document Pad..........................................................................10-6
Control Panel............................................................................10-7
10.3 Function Combination Table [CD].............................................10-7
10.4 Paper Size and Zoom Ratio Tables [CD]...................................10-7
11 Index
