LOW RISE - 4 LIGHT DUTY BATTENS (swaged) + 2 ‘X’ BRACES.
Component take-off Quantity
Upright 2
Baseplate 2
Upright to baseplate fixing (when required) 2
Light duty batten (swage holes) 4
Frame brace 4
Rivet 4.8 x 7mm 8
Issue: June 2005 Section E – Frame Assembly Schedule Page E.9
