LOW RISE - 3 HEAVY DUTY BATTENS (riveted) + 2 ‘X’ BRACES.
Component take-off Quantity
Upright 2
Baseplate 2
Upright to baseplate fixing (when required) 2
Heavy duty batten 3
Frame brace 4
Rivet 4.8 x 7mm 26
Issue: June 2005 Section E – Frame Assembly Schedule Page E.11
