HIGH RISE - 4 LIGHT DUTY BATTENS (swaged or riveted).
Component take-off Quantity
Upright 2
Baseplate 2
Upright to baseplate fixing (when required) 2
Light duty batten 4
Rivet 4.8 x 7mm (only for riveted frames) 16
The chart containing the schedule of dimensions is shown on the following page.
Issue: June 2005 Section E – Frame Assembly Schedule Page E.12
