Issue: June 2005 Section E – Frame Assembly Schedule Page E.35
HIGH RISE – FULLY BRACED with HEAVY DUTY BATTENS (riveted) (continued).
Frame No. of No. of Batten centres (mm) Material take-off
height panels extra battens braces rivets
‘H’ ‘N’ battens ‘A’ ‘B’ ‘C’ ‘D’
7600mm 6 - 189 7 12 66
7700mm 6 - 289 7 12 66
7800mm 6 - 389 7 12 66
7900mm 6 1 189 300 8 12 72
8000mm 6 1 189 400 8 12 72
8100mm 6 1 289 400 8 12 72
8200mm 6 1 389 400 8 12 72
8300mm 6 1 489 400 8 12 72
8400mm 6 2 189 9 12 78
8500mm 6 2 289 9 12 78
8600mm 6 2 389 9 12 78
8700mm 6 2 489 9 12 78
8800mm 7 - 189 8 14 76
8900mm 7 - 289 8 14 76
9000mm 7 - 389 8 14 76
9100mm 7 1 189 300 9 14 82
9200mm 7 1 189 400 9 14 82
9300mm 7 1 289 400 9 14 82
9400mm 7 1 389 400 9 14 82
9500mm 7 1 489 400 9 14 82
9600mm 7 2 189 10 14 88
9700mm 7 2 289 10 14 88
9800mm 7 2 389 10 14 88
9900mm 7 2 489 10 14 88
10000mm 8 - 189 9 16 86
10100mm 8 - 289 9 16 86
10200mm 8 - 389 9 16 86
10300mm 8 1 189 300 10 16 92
10400mm 8 1 189 400 10 16 92
10500mm 8 1 289 400 10 16 92
10600mm 8 1 389 400 10 16 92
10700mm 8 1 489 400 10 16 92
10800mm 8 2 189 11 16 98
10900mm 8 2 289 11 16 98
11000mm 8 2 389 11 16 98
11100mm 8 2 489 11 16 98
11200mm 9 - 189 10 18 96
11300mm 9 - 289 10 18 96
11400mm 9 - 389 10 18 96
11500mm 9 1 189 300 11 18 102
11600mm 9 1 189 400 11 18 102
11700mm 9 1 289 400 11 18 102
11800mm 9 1 389 400 11 18 102
11900mm 9 1 489 400 11 18 102
12000mm 9 2 189 12 18 108
