2300mm MULTI-TIER FRAME (Braced + Light duty riveted battens).
Component take-off Quantity
Upright 2
Baseplate 2
Upright to baseplate fixing (when required) 2
Light duty batten (rivet holes) 2
Frame brace for an 800mm high bracing panel 4
Rivet 4.8 x 7mm 16
Issue: June 2005 Section E – Frame Assembly Schedule Page E.41
