Dexter Laundry V-Series User Manual

WCVD18 Bolt Torque Chart
Bolt Size Where Used Torque
1/2-13 x 2 1/2” Front Mounting Clamp Ring Ends 20-30 ft-lb
1/2-13 x 1 1/4” Front and Rear Mounting Rings to Base 70-110 f t-lb
3/8-16 x 2” Tub Back Ring to Tub Back 45-80 ft-lb
1/2-13 x 1 1/2” Bearing House To Tub Back 70-110 ft-lb
3/8-16 x 1 3/4” Bearig Housing Pulley End 45-80 ft-lb
1/2-13 x 1 1/4” Hub of Driven Pulley 70-110 ft-lb
5/16-18 x 7/8” Drive Pulley Set Screws 190-200 in-lb
WCVD25 Bolt Torque Chart
Bolt Size Where Used Torque
1/2-13 x 2 1/2” Front Mounting Clamp Ring Ends 30-40 ft-lb
1/2-13 x 1 1/4” Front and Rear Mounting Rings to Base 70-110 f t-lb
3/8-16 x 2” Tub Back Ring to Tub Back 45-80 ft-lb
1/2-13 x 1 1/2” Bearing House To Tub Back 70-110 ft-lb
3/8-16 x 1 3/4” Bearig Housing Pulley End 45-80 ft-lb
1/2-13 x 1 1/4” Hub of Driven Pulley 70-110 ft-lb
5/16-18 x 7/8” Drive Pulley Set Screws 190-200 in-lb
WCVD40 Bolt Torque Chart
Bolt Size Where Used Torque
5/8-11 x 3” Front Mounting Clamp Ring Ends 60-80 ft-lb
5/8-11 x 1 1/2” Front and Rear Mounting Rings to Base 120-150 ft-lb
7/16-14 x 1 1/2” Tub Back Ring to Tub Back 100-125 ft-lb
5/8-11 x 1 1/2” Bearing House To Tub Back 120 -150 f t-lb
7/16-14 x 2” Bearig Housing Pulley End 100-125 ft-lb
5/8-11 x 1 1/2” Hub of Driven Pulley 120-150 in-lb
5/16-18 x 7/8” Drive Pulley Set Screws 190-200 in-lb
WCVD55 Bolt Torque Chart
Bolt Size Where Used Torque
1/2-13 x 2” Front Mounting Clamp Ring Ends 30-40 ft-lb
3/8-16 x 3” Front Clamp Ring 100 in-lb
1/2-13 x 2” Tub to Base 70-110 ft-lb
7/16-14 x 1” Bearing House To Tub Back 60-80 ft-lb
3/4-10 x 3” Bearig Housing to Base 200-300 ft-lb
7/16-14 x 1” Hub of Driven Pulley 28-32 ft-lb
1/4-20 x 1” Drive Pulley Set Screws 80 in-lb
WCVD18 Bolt Torque Chart
Bolt Size Where Used Torque
1/2-13 x 2” Front Mounting Clamp Ring Ends 30-40 ft-lb
3/8-16 x 3” Front Clamp Ring 100 in-lb
1/2-13 x 2” Tub to Base 70-110 ft-lb
7/16-14 x 1” Bearing House To Tub Back 60-80 ft-lb
3/4-10 x 3” Bearig Housing to Base 200-300 ft-lb
7/16-14 x 1” Hub of Driven Pulley 28-32 ft-lb
1/4-20 x 1” Drive Pulley Set Screws 80 in-lb
64 65
Part # 8533-050-001 2/22 Part # 8533-050-001 2/22
Machine
Mounting
Installation
& Operation
Programming
Trouble-
shooting
Machine
Service
Electrical
Wiring
Parts
Data
Coin
Handling
Maintenance
Service Elec.
Compnents
