Dexter Laundry V-Series User Manual

Wiring Harness Part # by Model
Part Number
9794-001-001
9627-791-003
9627-791-004
9627-792-001
9627-796-001
9627-796-002
8654-125-001
8653-074-001
9806-015-001
9806-015-003
9627-793-001
9627-794-001
9627-795-001
9627-795-002
9627-797-001
9627-800-001
9627-801-001
9627-802-001
9627-803-001
8220-064-023
8220-064-040
8220-062-025
8220-062-032
8220-001-282
8220-118-001
8220-108-007
8220-123-001
8220-128-001
8220-062-025
8220-062-028
8220-062-027
8220-063-008
8220-063-009
8220-117-001
9631-381-018
8220-090-009
8220-001-231
8220-001-478
9627-747-002
9627-747-003
9627-831-001
Description
Wiring Harness, ( Add Bleach Lite assy included ) ALL.............................1
Wiring Harness, DoorLock WCVD-18,WCVD-25.......................................1
Wiring Harness, Doorlock WCVD-40,WCVD-55, WCVD-75........................1
Wiring Harness,CoinDrop Mech ALL.......................................................1
Wiring Harness, Drain,Thermo,DoorSol WCVD-18,WCVD-25,WCVSD-40....1
Wiring Harness, Drain,Thermo,Door Sol. WCVD-55,WCVD-75..................1
Clamp, Cable- 1/4 Dia. ALL...................................................................1
Connector, Clear In-Line ALL...............................................................AR
Data Cable ALL xcpt. 75Ib....................................................................1
Data Cable WCVD-75............................................................................1
Wiring Harness P20/P21 ALL.................................................................1
Wiring Harness ,P8/P16 ALL.................................................................1
Wiring Harness WaterValve/P19 WCVD-18,WCVD-25..............................1
Wiring HarnessWaterValve/P19WCVD-55,WCVD-75,WCVD-40..................1
Wiring Harness ,LED PCB ALL...............................................................1
Wiring Harness ,PS/pressure WCVD-18...................................................1
Wiring Harness ,PS/pressure WCVD-25...................................................1
Wiring Harness ,PS/pressure WCVD-40...................................................1
Wiring Harness, PS/pressure WCVD-55, WCVD-75..................................1
Wiring Assembly Yel. 32" ALL except 75.................................................2
Wiring Assembly Yel. 64" WCVD-75........................................................2
Wiring Assembly Red 28" WCVD-40,WCVD-55........................................2
Wiring Assembly Red 41" WCVD-75........................................................2
Wiring Assembly Red 20" WCVD-18,WCVD-40,WCVD-25.........................2
Wiring Assembly Vio. 24" WCVD-18........................................................2
Wiring Assembly Wht/Brn 8" WCVD-75...................................................1
Wiring Assembly Jumper Yel WCVD-55,WCVD-18,WXCVD-40,WCVD-25....1
Wiring Assembly Jumper Yel WCVD-75...................................................1
Wiring Assembly Red 28" WCVD-55,WCVD-40.........................................2
Wiring Assembly Blk. 17" ALL................................................................1
Wiring Assembly Red 17" ALL................................................................1
Wiring Assembly Wht/Grn 16" WCVD-55,WCVD-40,WCVD-25...................1
Wiring Assembly Blu 16" WCVD-55,WCVD-40,WCVD-25..........................1
Wiring Assembly Jumper BLK.WCVD-40,WCVD-75,WCVD-25....................2
Wiring Assembly Red 7" ALL..................................................................1
Wiring Assembly Blu/Wht ALL................................................................1
Wiring Assembly Blk/Blu ALL.................................................................1
Wire Assembly Green 7" WCVD-18.........................................................1
Harness Power Terminal Block WCVD-55,WCVD-75.................................1
Harness Power Terminal Block WCVD-25, WCVD-40................................1
Harness Power Terminal Block WCVD-18 ...............................................1
94 95
Part # 8533-050-001 2/22 Part # 8533-050-001 2/22
94
Section 8:
Parts Data
V-Series Vended
Machine
Mounting
Installation
& Operation
Programming
Trouble-
shooting
Machine
Service
Electrical
Wiring
Parts
Data
Coin
Handling
Maintenance
Service Elec.
Compnents
Accessories
Kits &
Assemblies
Wiring
Harnesses
Cabinet &
Front Panel
Rear
View
Cylinder, Seals,
& Bearings
Door
Lock
Loading
Door
Chassis
& Drain
Water Inlet &
Rear Channel
Electrical
Components
Control
Panel
