Dexter Laundry V-Series User Manual

V-Series Accessories
WCVD18KCS-10 120 volt 60hz Single Phase
WCVD18KCS-12 208-240 volts 60hz Single Phase or Three Phase
WCVD25KCS-12 208-240 volts 60hz Single Phase or Three Phase
WCVD40KCS-12 208-240 volts 60hz Single Phase or Three Phase
WCVD55KCS-12 208-240 volts 60hz Single Phase or Three Phase
WCVD75KCS-12 208-240 volts 60hz Single Phase or Three Phase
Key Description T-300 T-400 T-600 T-900 T-1200 QTY
* Kit, Door Gasket Expander
(large)
9732-139-002 9732-139-002 9732-139-002 9732-139-002 9732-139-002
* Kit, Door Gasket Expander
(small)
9732-139-001 9732-139-001 9732-139-001 9732-139-001 9732-139-001
* Hose, Water Supply 3/8” I.D. x
48” (furnished 18lb, 25lb, 40lb)
9990-027-011 9990-027-011 9990-027-011 2
* Hose, Water Supply 5/8” I.D. x
48” (furnished 55lb, 75lb)
9990-027-013 9990-027-013 2
* Washer, Inlet Hose (furnished) 8641-242-000 8641-242-000 8641-242-000 8641-242-000 8641-242-000 2
* Strainer, Inlet Hose (furnished) 9565-003-001 9565-003-001 9565-003-001 9565-003-001 9565-003-001 2
* Drain Hose 10ft length x 2-1/4”
ID
9242-417-002 9242-417-002 9242-417-002 9242-417-002 9242-417-002
* Drain Hose 10ft length x 3” ID 9242-417-003 9242-417-003 9242-417-003 9242-417-003 9242-417-003
* Bevel Washer for 5/8” bolt used
in installations using angle iron
bases
8641-586-002 8641-586-002 8641-586-002 8641-586-002 8641-586-002
* Bevel Washer for 3/4” bolt used
in installations using angle iron
bases
8641-586-003 8641-586-003 8641-586-003 8641-586-003 8641-586-003
* Sealing compound 8538-151-001 8538-151-001 8538-151-001 8538-151-001 8538-151-001
* TORX#20 8545-051-002 8545-051-002 8545-051-002 8545-051-002 8545-051-002
* Special Tool for Removing Coin
Acceptor Mtg Screws (T-10 Torx)
8545-051-003 8545-051-003 8545-051-003 8545-051-003 8545-051-003
* Flow Restrictors (in dispenser ) 9475-002-002 9475-002-002 9475-002-002 9475-002-002 9475-002-002 2
* Battery (used on Control PCB) 8612-001-001 8612-001-001 8612-001-001 8612-001-001 8612-001-001
* Trailer Hitch Tool (55lb, 75lb) 8545-056-001 8545-056-001
* VFD Filter options (1 phase)
120v
9732-233-001
* VFD Filter options (3 phase) 9732-234-001 9732-231-001 9732-231-001 9732-231-001 9732-231-001
* VFD Filter options (1 phase)
220VAC
9732-235-001 9732-232-001 9732-232-001 9732-232-001 9732-232-001
* Bearing & Seal Kit 9732-219-001 9732-219-003 9732-219-005 9732-219-007 9732-219-007
* E-Stop Conversion Kit (V to
A-Series)
9732-226-001 9732-226-003 9732-226-005 9732-226-007 9732-226-009
* V & A-Series Conversion to
Manual Start for Small Vault
9732-224-001 9732-224-001 9732-224-001 9732-224-001 9732-224-001
Kits, Assemblies, & Common Parts
Coin Acceptor Components Part Number
Mechanical Coin Acceptor 9021-001-010
Coin Drop Screws 9545-053-002
Retainer, Coin Acceptor 9486-149-001
Loading Door & Door Lock Components Part Number
Door Glass Gasket (Standard Door) 9206-419-001
Door Glass Gasket (Small Door) 9206-411-002
Door Lock Solenoid Assembly 9922-011-001
Door Handle Only 9244-080-003
Kit - Door Latching Assy. & Cam (replaces original Door Latching Assembly) 9732-347-001
Kit - Door Cam Replacement 9732-346-002
Kit - Locking Pawl Replacement 9732-346-001
Kit - Door Gasket Expander Kit (Small) 9732-139-001
Kit - Door Gasket Expander Kit (Large) 9732-139-002
Electrical Components Part Number
Transformer, Main 8711-004-001
Transformer, Control 8711-009-001
Main Control Board 9473-004-007
VFD & Breaking Resistors Components Part Number
Breaking Resistor 200 Ohms 9483-004-002
Breaking Resistor 160 Ohms 9483-004-003
Delta E Drive Display 9150-044-001
MS 300 VFD Display 9150-058-001
Data Cable (56”) 9806-015-003
Drain & Water Valve Components Part Number
Kit - 3” Drain Valve Seal Replacement 9732-327-001
Drain Valve 3” 9379-202-001
Drain Valve 2” 9379-199-001
Water Valve (Dual) 9379-183-012
Water Valve (Single Mueller) 9379-194 -001
Diaphragm (Dual) 9118-049-003
Diaphragm (Single Mueller) 9118-055-001
Cabinet Components Part Number
Front Panel Screw 9545-008-014
Front Panel Finisher Washer 8641-585-001
Front Panel Spring Nut 8640-399-008
Top Soap Box Screw 9545-008-012
Top Soap Box Spring Nut 8640-399-007
5/16 Hex Screw, Common 9545-008-026
Top Lock Key #6324 9306-025-001
Cylinder Plug (1.5” Plastic) 9456-041-007
92 93
Part # 8533-050-001 2/22 Part # 8533-050-001 2/22
92
Machine
Mounting
Installation
& Operation
Programming
Trouble-
shooting
Machine
Service
Electrical
Wiring
Parts
Data
Coin
Handling
Maintenance
Service Elec.
Compnents
Control
Panel
Electrical
Components
Water Inlet &
Rear Channel
Chassis
& Drain
Loading
Door
Door
Lock
Cylinder, Seals,
& Bearings
Rear
View
Cabinet &
Front Panel
Wiring
Harnesses
Kits &
Assemblies
Accessories
