Introduction
ISA Interface
Rear Panel I/O
Ports
I/O Connectors
BIOS
Energy Efficient
Design
Dam a g e Fre e
Intelligence
Temperature
Humidity
PCB
•ITEIT8888G:PCItoISAslotbridge
- 3 ISA slots
- Does not support ISA Master devices and ISA DMA devices
•1mini-DIN-6PS/2mouseport
•1mini-DIN-6PS/2keyboardport
•2DB-9serialports
- Supports RS232/422/485
- Pins 1 and 9 of RS232 functions as RS232 signal or power
(selectable via jumper)
•1DB-15VGAport
•1DVI-Iport(DVI-Dsignalonly)
•2RJ45LANports
•4USB2.0/1.1ports
•Mic-in,line-inandlineoutjacks
•2connectorsfor4externalUSB2.0/1.1ports
•6connectorsfor6externalRS232serialports
•18-bitDigitalI/Oconnector
•1frontaudioconnectorforline-outandmic-injacks
•1CD-inconnector
•1S/PDIFconnector
•4SerialATAconnectors
•140-pinIDEconnector
•125-pinparallelconnector
•124-pinATXpowerconnector
•14-pin12Vpowerconnector
•1chassisintrusionconnector
•1frontpanelconnector
•3fanconnectors
•AMIBIOS
•8MbitSPIBIOS
•ACPIv3.0bspecification
•SystemPowerManagement
•Wake-On-Eventsinclude:
- Wake-On-PS/2 Keyboard/Mouse
- Wake-On-USB Keyboard/Mouse
- Wake-On-LAN
•Microsoft
®
/Intel
®
APM 1.2 compliant
•ACpowerfailurerecovery
•MonitorsCPU/System/AUXtemperatureandoverheatalarm
•MonitorsCPU/DIMM/NB/5V/12V/1.1V/VBATvoltagesand
failure alarm
•MonitorsCPU/System/2ndfanspeedandfailurealarm
•Readbackcapabilitythatdisplaystemperature,voltageand
fan speed
•Watchdogtimerfunction
•0
o
C to 60
o
C
•10%to90%
•ATXformfactor
•305mm(12”)x244mm(9.6”)
