Introduction
Processor
Chipset
System Memory
Expansion Slots
Graphics
Audio
LAN
Serial ATA
Interface
IDE
Super I/O
Chapter 1 - Introduction
•LGA775socketfor:
- Intel
®
Core
TM
2 Quad Q9400
- Intel
®
Core
TM
2 Duo E8400/E7400/E6400/E4300
- Intel
®
Pentium
®
E6500/E5300/E2160
- Intel
®
Celeron
®
E3400/E1500/440
•IntelEnhancedMemory64Technology(EM64T)
•EnhancedIntelSpeedStepTechnology(EIST)
•1333/1066/800MHzFSB
•Intel
®
chipset
- Intel
®
G41Expresschipset
- Intel
®
ICH7R I/O Controller Hub
•Two240-pinDDR3DIMMsockets
•SupportsDDR3800/1066MHzDIMM
•Maximum memory bandwidth of 17GB/s in dual-channel
mode when using DDR3 1066MHz
•Supportsdualchannelmemoryinterface
•Supportsupto4GBsystemmemory
•Supportsunbufferedx8andx16DIMMs
•5PCIslots(PCI2.3)
•3ISAslots
Note: 1 PCI and 1 ISA are shared slots.
•IntegratedIntelGMAX4500
 - 3D,2Dandvideocapabilities,DX10andOpenGL2.1
•Displayports:DVI-I(ChrontelCH7307C)andVGA
•RealtekALC2622-channelHighDefinitionAudio
•HighperformanceDACswith100dBSNR
•ADCswith90dBSNR
•Two stereo DACs support 24-bit PCM format for stereo au-
dio playback
•Three stereo ADCs support 20-bit PCM format for multiple
input streaming
•S/PDIFaudiointerface
•2 Realtek RTL8111DLPCI Express Gigabit Ethernet control-
lers
•10Mbps,100Mbpsand1Gbpsdatatransmission
•IEEE802.3u(10/100Mbps)andIEEE802.3ab(1Gbps)com-
pliant
•4SerialATAportscompliantwithSATA1.0aspecification
•SATAspeedupto3Gb/s(SATA2.0)
•SupportsuptotwoIDEdevices
•UltraATA100/66/33
•Winbond W83627DHG-P: supports 8-bit Digital I/O and
printer port
•FintekF81217U:supportsCOM1toCOM4
•FintekF81217U:supportsCOM5toCOM8
Specifications
