47
2
Hardwar
e
Installation
REV
.1
Cooling
Fan
Connectors
The
fan
connectors
are
used
to
connect
cooling
fans.
The
cooling
fans
will
provide
adequate
airow
throughout
the
chassis
to
prevent
overheating
the
CPU
and
sys-
tem
board
components.
BIOS
Setting
The
PC
Health
Status
submenu
of
the
BIOS
will
display
the
current
speed
of
the
cooling
fans.
R
efer
to
chapter
3
for
more
information.
CPU
fan
System
fan
2nd
fan
1
4
Sense
Power
Ground
Speed
Control
1
3
Sense
Power
Ground
1
3
Sense
Power
Ground
46
48
