Hardware Installation
REV.1
JP1 is used to select the power of the PS/2 keyboard/mouse port. Selecting
+5V_standby will allow you to use the PS/2 keyboard or PS/2 mouse to wake up
the system.
BIOS Setting
Congure the PS/2 keyboard/mouse wake up function in the Integrated Periph-
erals submenu (“Super IO Device” section) of the BIOS. Refer to chapter 3 for
more information.
Important:
The+5VSBpowersourceofyourpowersupplymustsupport≥720mA.
PS/2 Power Select
JP1
2-3 On:
+5V_standby
1-2 On: +5V
(default)
31 2
31 2
