BIOS Setup
PCI Express Configuration
This section is used to congure PCI Express.
SB PCIE Ports Conguration
Congures the PCI Express ports.
BIOS SETUP UTILITY
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
PCI Express Conguration

SB PCIE Ports Conguration
Advanced
Congure South
bridge PCIE features
G-LAN Port 1 and G-LAN Port 2
The options are Auto, Enabled and Disabled.
PCIE High Priority Port
Selects the highest priority PCIE port.
BIOS SETUP UTILITY
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
← Select Screen
↑↓ Select Item
+
-
Change Option
F1 General Help
F10 Save and Exit
ESC Exit
PCIE Ports Conguration
G-LAN Port 1
G-LAN Port 2
PCIE High Priority Port
Advanced
[Auto]
[Auto]
[Disabled]
Auto
Enabled
Disabled
Options
