40
2
Hardware Installation
REV.1
I/O Connectors
CD-in Internal Audio Connector
The CD-in connector is used to receive audio from a CD-ROM drive, TV tuner or
MPEGcard.
4
1
Leftaudio
channel
Rightaudio
channel
Ground
Ground
