DFI EL620-C - SATA (Serial ATA) Connectors

43
2
Hardware Installation
The Serial ATA connectors are used to connect Serial ATA devices. Connect one
endoftheSerialATAcabletoaSATAconnectorandtheotherendtoyourSerial
ATAdevice.
BIOS Setting
Congure the Serial ATA drives in the Integrated Peripherals submenu (“OnChip
IDEDevice”section)oftheBIOS.Refertochapter3formoreinformation.
SATA (Serial ATA) Connectors
REV.1
SATA3
SATA1
SATA2
SATA0
1
RXN
GND
TXP
TXN
GND
7
RXP
GND
