DFI EL620-C - Audio

39
2
Hardware Installation
REV.1
Audio
Line-out
Line-in
Mic-in
Rearaudio
Front
audio
Rear Audio
Thesystemboardisequippedwith3audiojacks.Ajackisaone-holeconnecting
interfaceforinsertingaplug.
• Mic-inJack(Pink)
 Thisjackisusedtoconnectanexternalmicrophone.
• Line-inJack(LightBlue)
 This jack is used to connect any audio devices such as Hi- set, CD player,
tapeplayer,AM/FMradiotuner,synthesizer,etc.
• Line-outJack(Lime)
 Thisjackisusedtoconnectaheadphoneorexternalspeakers.
Front Audio
The front audio connector allows youto connect to the second line-out and mic-
injacksthatareatthefrontpanelofyoursystem.
Driver Installation
Installtheaudiodriver.Refertochapter4formoreinformation.
10
Mic2-L
Line2-R
Front_IO_Sense
GND
PresenceSignal
Key
9
1
Mic2-JD
Line2-JD
2
Mic2-R
Line2-L
