Hardware Installation
Wake-On-USB Keyboard/Mouse
TheWake-On-USBKeyboard/MousefunctionallowsyoutouseaUSBkeyboardor
USBmousetowakeupasystemfromtheS3(STR-SuspendToRAM)state.To
usethisfunction:
• JumperSetting
 JP4 and/or JP7 must be set to “2-3 On: +5V_standby”. Refer to “USB Power
Select”inthischapterformoreinformation.
• BIOSSetting
 “USBKBWake-UpFromS3”inthePowerManagementSetupsubmenuofthe
BIOSmustbesettoEnabled.Refertochapter3formoreinformation.
Important:
If you are using the Wake-On-USB Keyboard/Mouse function for 2 USB
ports, the +5V_standby power source of your power supply must sup-
port≥1.5A. For3or more USB ports, the +5V_standby power sourceof
yourpowersupplymustsupport≥2A.
