2.3. Assembled Analyzer
2.3.1. ABACUS 4
Front Panel:
Rear panel:
Back door to access
pump and main
dilutor
Reagent inlets
Power switch
Keyboard
Serial Port
Function keys
Foil keypad
320×240 dots,
64 color LCD
display
Start button
Sample rotor
USB A Port
USB B Port
