SM-200 TE Grinding and Honing Machine
46
Setting up the Machine
8
Special accessories for sharpening circular blades:
• Adapter set for circular blades
- Centring pieces
- Clamping discs
• Special accessories depending on the diameter of the circu-
lar blade:
- Circular blade grinding arm ø 70 mm – ø 180 mm
- Circular blade grinding lever ø 180 mm – ø 500 mm
- Circular blade guard ø 200 mm – ø 500 mm
All special accessories require different set-up steps.
General preparatory work:
Prepare the universal grinding arm for radial grinding, see page 37.
1 Fasten the sliding carriage.
2 Release the rotary function of the universal mounting head.
Step 1 is not required on the radial grinding arm.
On both grinding arm versions:
3 Move the grinding angle device to the approximate position
required after loosening the clamping lever.
4 Choose a centring piece suitable for the circular blade from
the adapter set.
Now different work is required for the different knife sizes.
Circular blades ø 70mm – ø 180mm
1 Remove the universal mounting head.
2 Mount the circular blade grinding arm.
3 Tilt the circular blade grinding arm backwards. Loosen the
mounting screw on the underside with a hexagon socket key.
4 Remove the clamping disc.
5 Place the circular blade with the centring piece on the circular
blade grinding arm.
6 Mount the clamping disc again with the mounting screw.
7 Tilt the circular blade grinding arm forwards.
