SM-200 TE Grinding and Honing Machine 47
Setting up the Machine
8
8 Adjust the grinding angle with the foot pedal. Adjust the hori-
zontal and vertical position of the grinding device if necessary.
Contact point of the knife edge at approximately 1-2 o'clock on
the grinding wheel.
Circular blades ø 180mm – ø 200mm
1 Clamp the rotary axis on the universal mounting head, see
page 38.
2 Remove the double grinding lever of the universal mounting
head.
3 Place the stopper disc from the adapter set on the universal
mounting head.
4 Place the centring piece and circular blade on the universal
mounting head.
5 Screw together the clamping flange and circular blade grind-
ing lever.
6 Release the rotary axis on the universal mounting head again.
7 Adjust the grinding angle with the foot pedal. Adjust the hori-
zontal and vertical position of the grinding device if necessary.
Contact point of the knife edge at approximately 1-2 o'clock on
the grinding wheel.
Circular blades ø 200mm – ø 500mm
1 Remove the universal mounting head.
2 Mount the circular blade guard on the grinding arm.
3 Place the centring piece and circular blade on the circular
blade guard.
4 Screw together the clamping flange and circular blade guard.
5 Adjust the grinding angle with the foot pedal. Adjust the hori-
zontal and vertical position of the grinding device if necessary.
Contact point of the knife edge at approximately 1-2 o'clock on
the grinding wheel.
