OPERATOR’S MANUAL
PM300E and PM332E Planter Monitors
11001-1423-200710
38 / ALARMS
SHAFT SPEED LOW/HI LIMIT WARNING
Alarm sounds when any shaft speed exceeds or falls below the value
entered for Shaft Speed Lo or Hi Limits in the Setup mode. Alarm can be
silenced by pressing Alarm Cancel key, but will re-activate if problem is not
resolved.
Figure 29
Shaft Speed Limit Warning Display (Optional)
FLOW LOW/HI LIMIT WARNING
An alarm will sound when flow inputs exceed or fall below the value entered
for the Flow Lo or Hi Limits in the Setup mode. Alarm can be silenced by
pressing Alarm Cancel key, but will re-activate if problem is not resolved.
Figure 30
Flow Low/ Hi Limit Warning Display (Optional)
LOW SHAFT SPEED
HI SHAFT SPEED
LOW FLOW RATE
HIGH FLOW RATE
