OPERATOR’S MANUAL
PM300E and PM332E Planter Monitors
11001-1423-200710
INTRODUCTION / 5
SPECIFICATIONS
Power 10.5–16 VDC, 5 A maximum
Operating temperature range -20°C to 70°C (-4°F to 158°F)
Storage temperature range -40°C to 85°C (-40°F to 185°F)
Size 18.4 cm W x 20.1 cm H x 4.3 cm D
(7.3" W x 7.9" H x 1.7" D)
Weight 4.4 lbs for 16-row PM300E system
4.8 lbs for 32-row PM332E system
*Weight includes console and attached
cables (battery power cable and signal
cable that extends to the drawbar).
Wire Harnesses The PM300E and PM332E include
integrated harnesses to supply the unit's
power (fused), ground speed input, and
sensor inputs (to drawbar). The connectors
are compatible with existing DICKEY-john
harnesses. DICKEY-john can supply
custom harnesses required for sensor
inputs.
Sensors Compatible with existing DICKEY-john
sensors
Standard mounting Rear attached horizontal or vertical
mounting bracket
Mounting bracket weighs 1.0 lb.
Contrast adjustment Automatic temperature compensation for
contrast
Dust and moisture resistant Cab installation only
