About the development board J26 pinout
ConnectCore for i.MX51 Hardware Reference Manual
100
Pin Signal Pin Signal
111 EIM_DA16/TRACE0 112 EIM_DA21/TRACE5
113 EIM_DA18/TRACE2 114 EIM_DA23/TRACE7
115 +3.15V 116 EIM_DA25/TRACE9
117 EIM_DA20/TRACE4 118 EIM_DA27/TRACE11
119 EIM_DA22/TRACE6 120 EIM_DA29/TRACE13
121 EIM_DA24/TRACE8 122 EIM_DA31/TRACE15
123 EIM_DA26/TRACE10 124 EIM_A17/GPIO2_11
125 EIM_DA28/TRACE12 126 EIM_A19/GPIO2_13
127 EIM_DA30/TRACE14 128 EIM_A21/GPIO2_15
129 EIM_A16/GPIO2_10 130 EIM_A23/GPIO2_17
131 EIM_A18/GPIO2_12 132 EIM_A25/GPIO2_19
133 EIM_A20/GPIO2_14 134 EIM_A27/GPIO2_21
135 EIM_A22/GPIO2_16 136 EIM_OE#/GPIO2_24
137 EIM_A24/GPIO2_18 138 EIM_RW#
139 EIM_A26.GPIO2_20 140 EIM_CRE/GPIO3_2
141 EIM_EB0 142 EIM_WAIT
143 EIM_EB1 144 GND
145 EIM_EB2/GPIO2_22/TRCTL 146 EIM_BCLK
147 EIM_EB3/GPIO2_23/TRCLK 148 GND
149 NANDF_ALE/GPIO3_5 150 NAND_RE#/SD3_DATA1/GPIO3_4
151 NANDF_WP#/SD3_DATA2/GPIO3_7 152 NANDF_CLE/GPIO3_6
153 NANDF_RB1_SP12_RDY/GPIO3_9 154 NANDF_RB0/SD3_DATA3/GPIO3_8
155 NANDF_RB3/SP12_MISO/GPIO3_11 156 NANDF_R2/SP12_SCLK/GPIO3_10
157 - 158 -
159 - 160 -
J26 pinout
Pin Signal Pin Signal
1 DISP1_DAT0 2 DISP1_DAT1
3 DISP1_DAT2 4 DISP1_DAT3
