About the development board LCD interfaces
ConnectCore for i.MX51 Hardware Reference Manual
92
Pin Function Pin Function
35 LCD1_DATA4 (B6) 36 LCD1_DATA5 (B7)
37 - 38 -
39 - 40 -
41 GND 42 GND
43 LCD1_BIAS 44 LCD1_PCLK
45 LCD1_PWREN# 46 GND
47 LCD1_VSYNC 48 LCD1_HSYNC
49 - 50 -
51 - 52 -
53 - 54 -
55 GND 56 GND
57 TOUCH_X1 58 TOUCH_Y1
59 TOUCH_X2 60 TOUCH_Y2
61 I2C
2
_SDA 62 I2C
2
_SCL
63 LCD_SPI_SS# 64 SPI1_CLK
65 SPI1_MOSI 66 SPI1_MISO
67 RESET# 68 LCD1_TOUCH_INT/EXT#
69 LCD1_GPIO1 70 LCD1_GPIO2
71 LCD_PENIRQ 72 GND
73 +3.3V 74 +3.3V
75 +9-30V 76 +9-30V
77 +9-30V 78 +9-30V
79 - 80 -
LCD 2 connector, P2
This connector provides access to the following capabilities:
n 18-bit (RGB x 8bit) LCD
n SPI bus for a touch screen controller
n Touch screen (on-module, shared with LCD1)
n Interrupt input for touch screen
n I
2
C bus
