Digi ConnectCore Hardware Reference Manual

Module specifications Mechanical specifications
ConnectCore for i.MX51 Hardware Reference Manual
126
Mechanical specifications
Length 82 mm (3.228 inches)
Width: 50 mm (1.968 inches)
Height :
PCB: 1.40 mm (0.055 inches)
Top side part: 3.60 mm (0.142 inches)
Bottom side part: 2.20 mm (0.087 inches)
Fasteners and appropriate torque
We recommend using a M2x8mm PCB standoff with a slotted cheese head screw, DIN 84, M2x04, 6MM
(Digi P/N MA00898) in combination with a flat washer, DIN 125, M2, Nylon 6 (Digi P/N MA01617).
Additionally, we recommend the use of a torque key with 10 cNm.
Do not use a standard metal M2 washer.
Environmental specifications
Operating temperature: 600MHz variant:
-40º C to +85º C (-40º F to +185º F)
800MHz variant:
-20º C to +70º C (-4º F to +158º F)
Storage temperature: -40º C to +125º C (-40º F to +257º sF)
Network interface
Antenna specifications: 802.11 a/b/g antenna
Attributes
Attribute Band 1 Band 2
Frequency 2.4 ~ 2.4835 GHz 5.15 ~ 6 GHz
Bandwidth 120MHz 875MHz
Wavelength 1/4 Wave 1/4 Wave
Impedance 50 Ohm 50 Ohm
VSWR < 19 typ. Center < 19 typ. Center
Connector RP-SMA RP-SMA
