About the development board Camera interfaces

ConnectCore for i.MX51 Hardware Reference Manual

X15 pinout

Pin Signal Pin Signal

1 +2.775V 2 GND

3 CSI1_D12 4 CSI1_D13

5 CSI1_D14 6 CSI1_D15

7 CSI1_D16 8 CSI1_D17

9 CSI1_D18 10 CSI1_D19

11 CSI1_MCLK 12 CSI1_PIXCLK

13 CSI1_HSYNC/GPIO3_15 14 CSI1_VSYNC/GPIO3_14

15 GPIO1_2/I2C2_SCL 16 GPIO1_3/I2C2_SDA

17 CSI1_D10 18 CAMRESET1#/GPIO3_13/CSI1_D19

19 GND 20 CSI1_D11

X17 pinout

Pin Signal Pin Signal

1 +2.775V 2 GND

3 CSI2_D12/GPIO4_9 4 CSI2_D13/GPIO4_10

5 CSI2_D14 6 CSI2_D15

7 CSI2_D16 8 CSI2_D17

9 CSI2_D18/GPIO4_11 10 CSI2_D19/GPIO4_12

11 CSI1_MCLK 12 CSI2_PIXCLK/GPIO4_15

13 CSI2_HSYNC/GPIO4_14 14 CSI2_VSYNC/GPIO4_13

15 GPIO1_2/I2SC2_SCL 16 GPIO1_3/I2C2_SDA

17 - 18 CAMRESET2#/APIO3_7

19 GND 20 -
