About the development board LCD interfaces
ConnectCore for i.MX51 Hardware Reference Manual
90
Pin Function Pin Function
13 JTAG_TDO 14 GND
15 JTAG_RESET# 16 GND
17 JTAG_DE# 18 GND
19 GND 20 GND
Note In order to enable ETM functionality, Digi offers an optional ETM adapter board (sold separately,
Digi P/N CC-ACC-MX51-ETM). Please contact us.
LCD interfaces
The development board provides two 2x40 pin, 1.27mm connectors for accessing a Digi-provided LCD
application boards (CC-ACC0LCDW-70) or a user defined LCD application board.
