Pin I/O Type Signal name Use on module
Use on
development
board
Comments
J1:62 GPIO27 DISPB2_SER_DIO/GPIO3_
6
i.MX51: DISPB2_
SER_DIO
User button 1
& Digital IO 7
J1:63 GPIO27 DISP2_DATA0/MII_
RXD3/USBH3_CLK
i.MX51: DISP2_
DATA0
ETH_PHY: RXD3
LCD2 Data Ethernet 1
and LCD2
cannot be
used at the
same time.
J1:64 GPIO27 DISPB2_SER_CLK_
GPIO3_7
i.MX51: DISPB2_
SER_CLK
Camera 2
Reset
J1:65 HSGPIO2
7
DISP2_DATA2 i.MX51: DISP2_
DATA2
LCD2 Data
J1:66 GPIO27 DISP2_DATA1/MII_RX_
ER/USBH3_DIR
i.MX51: DISP2_
DATA1
ETH_PHY: RXD4
LCD2 Data Ethernet 1
and LCD2
cannot be
used at the
same time.
J1:67 HSGPIO2
7
DISP2_DATA4 i.MX51: DISP2_
DATA4
LCD2 Data
J1:68 HSGPIO2
7
DISP2_DATA3 i.MX51: DISP2_
DATA3
LCD2 Data
J1:69 GPIO27 DISP2_DATA6/MII_
TXD1/USBH3_STP
i.MX51: DISP2_
DATA6
ETH_PHY: TXD1
LCD2 Data Ethernet 1
and LCD2
cannot be
used at the
same time.
J1:70 HSGPIO2
7
DISP2_DATA5 i.MX51: DISP2_
DATA5
LCD2 Data Ethernet 1
and LCD2
cannot be
used at the
same time.
J1:71 GPIO27 DISP2_DATA8/MII_
TXD3/USBH3_DATA0
i.MX51: DISP2_
DATA8
ETH_PHY: TDX3
LCD2 Data Ethernet 1
and LCD2
cannot be
used at the
same time.
