D-Control Guide16
Stand Components
Unpack the stand and confirm that you have all of the necessary parts. Figure 2 shows the metal parts of the stand. Figure 3 shows
the plastics parts of the stand. Set the plastic parts aside to protect them from damage during initial assembly.
Figure 2. D-Control metal stand parts
Left leg assembly Right leg assembly Rear crossbar assembly
Front pan support rail
Rear pan support rail
Figure 3. D-Control plastic stand parts
Left and right side caps
(2) Leg front caps
(2) Leg rear caps
