Chapter 6: Channel Strip Controls 53
Pan Switch
When you press the Pan switch, the pan controls for the chan-
nel strip are displayed on the encoder displays.
If the track is a multichannel track, its Page Up switch lights to
indicate that there are multiple pages of pan controls. Multi-
channel pan controls are arranged as follows:
To open/close the Output window on-screen for a track:
1 Press the Pan switch on the channel.
2 Hold Start (Windows) or Control (Mac) and press the chan-
nel’s encoder switch.
Two-Knob Surround Panning
When working in surround, you can link the front and rear
pan controls on D-Control to facilitate X-axis motion in the
sound field.
To link front and rear surround panners:
1 Press the Operation switch in Console Prefs section until
“2KbPan” appears in the Soft Keys.
2 Press the Soft Key that corresponds to “2KbPan” to toggle
the preference on or off.
Bypass/Spill Switch
The function of the Bypass/Spill switch depends on what is
currently displayed on the channel strip.
Inserts
In the top level Inserts view (when plug-in names are dis-
played on a channel strip’s encoders), the Bypass/Spill switch
bypasses all plug-ins on that channel.
When a single plug-in’s parameters are displayed on a chan-
nels strip’s encoders, the Bypass/Spill switch bypasses that
plug-in only.
Sends
In the top level Sends view (when send names are displayed
on a channel strip’s encoders), the Bypass/Spill switch mutes
all sends on that channel.
When a single send’s parameters are displayed on a chan-
nels strip’s encoders, the Bypass/Spill switch has no effect.
VCA Master Tracks
On VCA Master tracks, the Bypass/Spill switch displays (or
“spills”) the slave tracks for the VCA in Custom Faders.
Sends Switch
When you press the Sends switch on a channel strip, sends are
shown in two groups of five (Sends A–E or Sends F–J) on the
encoder displays. The rotary encoders control Send level.
You can use Flip mode to transfer controls for any send posi-
tion (A–J) to the Faders. See “Flip Mode” on page 133.
To toggle display of Sends A–E and F–J on a channel strip:
1 Press the Sends switch in the Channel Strip Mode controls
section of the channel strip to show the top level Send display.
2 Press the Page Up and Page Down switches to toggle the top
level Send display between the two sets of five sends (A–E and
F–J).
To open/close a Send window on-screen:
1 Press the Sends switch on the channel whose Send window
you want to open/close.
2 Hold Start (Windows) or Control (Mac) and press the en-
coder Select switch for the Send you want to open/close.
Surround Pan Display, Page 1
Display Pan Control
LFE LFE channel
Cntr% Center Speaker Percentage
F Div Front Divergence
Rear Rear Pan
F/R Front/Rear Balance
Front Front Pan
Surround Pan Display, Page 2
Display Pan Control
R Div Rear Divergence
Rear Rear Pan
F/R Div Front/Rear Divergence
F/R Front/Rear Balance
F Div Front Divergence
Front Front Pan
