Mbox 2 Mini Setup Guide
70
6 From the Output pop-up menu, choose the output port on your MIDI interface that is con-
nected to the MIDI In of your instrument.
7 Enable the appropriate MIDI channels (1–16) for the Send Channels and Receive Channels
options (These determine which channels send and receive MIDI.)
Instrument Name
The Instrument Name field shows the user-definable instrument name for the currently se-
lected instrument.
Manufacturer
The Manufacturer pop-up menu provides a list of MIDI equipment manufacturers. This list is
derived from the XML-based MIDI device files provided with your Pro Tools installation.
Model
The Model pop-up menu provides a list of MIDI devices, filtered by the manufacturer name.
This list is derived from the XML-based MIDI device files provided with your Pro Tools instal-
lation.
Input Port
The Input Port pop-up menu displays a list of available MIDI interface input ports. Inputs will
include any MIDI interfaces enabled on your system. The MIDI interface port that is set and
displayed here is the port through which MIDI data is sent from the external MIDI device
specified in the Instrument Name field into your MIDI interface.
For more information, see “MIDI Patch Name Support” on page 71.
For more information, see “MIDI Patch Name Support” on page 71.
If you set the input port to None, the defined instrument will not appear as a choice in a MIDI
Input selector.
