Appendix B: Configuring MIDI Studio Setup (Windows Only) 71
Output Port
The Output Port pop-up menu displays a list of available MIDI interface output ports. The port
set and displayed here is the port through which MIDI data is sent from your MIDI interface
to the MIDI device specified in the Instrument Name field.
Send Channels
The Send Channels grid sets the send channels for the MIDI device specified in the Instrument
Name field.
Receive Channels
The Receive Channels grid sets the receive channels for the MIDI device specified in the In-
strument Name field.
MIDI Patch Name Support
Pro Tools supports XML (Extensible Markup Language) for storing and importing patch
names for your external MIDI devices. Pro Tools installs MIDI patch name files (.midnam) for
the factory default patch names of many common MIDI devices. These files reside in directo-
ries, sorted by manufacturer, in Program Files\ Common Files\Digidesign\MIDI Patch
Names\ Digidesign.
To import MIDI patch names into Pro Tools:
1 Verify the MIDI Device name in the MIDI Studio Setup window (see “MIDI Studio Setup” on
page 67).
2 Verify the MIDI track’s output is correctly assigned to the MIDI device.
If you set the output port to None, the defined instrument will not appear as a choice in a MIDI
Output selector.
