DG-BG4300NU User
Manual
57
The following table describes the parameters of this page:
Field Description
Default Route Selection You can select Auto or Specified.
VPI
The virtual path between two points in an ATM network,
ranging from 0 to 255.
VCI
The virtual channel between two points in an ATM network,
ranging from 32 to 65535 (1 to 31 are reserved for known
protocols)
Encapsulation You can choose LLC and VC-Mux.
Channel Mode
You can choose 1483 Bridged, 1483 MER, PPPoE, PPPoA,
1483 Routed or IPoA.
Enable NAPT
Select it to enable Network Address Port Translation (NAPT)
function. If you do not select it and you want to access the
Internet normally, you must add a route on the uplink
equipment. Otherwise, the access to the Internet fails.
Normally, it is enabled.
Enable IGMP
You can enable or disable Internet Group Management
Protocol (IGMP) function.
PPP Settings
User Name
Enter the correct user name for PPP dial-up, which is provided
by your ISP.
Password
Enter the correct password for PPP dial-up, which is provided
by your ISP.
Type You can choose Continuous, Connect on Demand, or Manual.
Idle Time (min)
If set the type to Connect on Demand, you need to enter the
idle timeout time. Within the preset minutes, if the router does
not detect the flow of the user continuously, the router
automatically disconnects the PPPoE connection.
WAN IP Settings
Type
You can choose Fixed IP or DHCP.
•
If select Fixed IP, you should enter the local IP address,
To Next Page
