DG-BG4300NU User
Manual
68
authentication and improved data encryption.
Set WEP Key
It is available when you set the encryption mode t o W EP.
Click it, the Wireless WEP Key Setup page appears.
WPA Authentication
Mode
•
Select Personal (Pre-Shared Key), enter the
pre-shared key in the Pre-Shared Key field.
•
Select Enterprise (RADIUS), enter the port, IP address,
and password of the Radius server.
You need to enter the username and password provided by
the Radius server when the wireless client connects the
router.
If the encryption is set to WEP, the router uses 802.1x
authentication, which is Radius authentication.
Click Set WEP Key, as shown in the screen above and the following screen appears.
