DG-BG4300NU User
Manual
95
The following table describes the parameters and buttons of this page:
Field Description
Direction Select
Select the router interface. You can select LAN or WAN. In
this example, LAN is selected.
LAN ACL Switch Select it to enable or disable ACL function.
IP Address
Enter the IP address of the specified interface. Only the IP
address that is in the same network segment with the IP
address of the specified interface can access the router.
Services Allowed
You can choose the following services from LAN: Web,
Telnet, SSH, FTP, TFTP, SNMP, or PING. You can also
choose all the services.
Add
After setting the parameters, click it to add an entry to the
Current ACL Table.
Reset Click it to refresh this page.
Current ACL Table Displays the services that are added and are active.
