DG-BG4300NU User Manual
96
Set direction of the data packets to WAN, the page shown in the following figure appears.
The following table describes the parameters and buttons of this page:
Field Description
Direction Select
Select the router interface. You can select LAN or WAN.
In this example, WAN is selected.
WAN Setting
You can choose Interface or IP Address. When IP
address option is selected only then IP address field will
appear.
IP Address
Enter the IP address on the WAN. Only the IP address
that is in the same network segment with the IP address
on the WAN can access the router.
WAN Interface Choose the interface that permits data packets from
