Digistar SCALE LINK SL2 - SLC2810 Remote Connection

62 pages

Save Page as PDF

To Next Page

To Previous Page

10 Scale Link 2 Technical Manual D4204-EN

SLC2810 Remote Connection

Header Pinout:

8-7-6-5-4-3-2-1

SLC Remote Port – Proprietary SPI Bus

*Note: +V is fused at 750mA on this port
