PART NUMBER CONFIGURATION AND OPTIONS
SL2XXX ABC/123/XYZ
Example 1: 410624 SL2140 ISO 4M12/R/S/ACC
This is a compact enclosure with 4 individual scale platforms. It contains an ISOBUS port with 4 M12 load cell
connections, a SLC remote port, a RS232 serial port, and an empty ACC port for IO.
Example 2: 410613 SL2110 ISO/4TB – NO CABLES
This is a compact enclosure for 1 scale platform, with 4 internal terminal blocks for load cell connections. ISOBUS is
enabled and other functions available, but no cables or connectors installed.
Example 3: 410619 SL2220 ISO 8TB/R/S
This is a full size enclosure with 2 individual scale platforms, setup for ISOBUS, SLC remote connections, and serial
port. It has 2 rows of 4 load cell terminal block connections on an additional terminal block PCB for 8 bars total.
Scale Link 2
Box Size
1 = small
2 = large
Number of Scale Platforms
10 = Single Platform A
20 = Dual Platform A-B
40 = Quad Platform A-B-C-D
Option Descriptions
2M12 = Two M12 Load Cell Ports
4M12 = Four M12 Load Cell Ports
4TB = Four Load Cell Connectors
8TB = Eight Load Cell Connectors
2WP = Two Pin Weather Pack
6WP = Six Pin Weather Pack
DB9 = RS232 Cable for PC
F = Wire Ferrules Installed
ISO = ISOBUS Enabled
NO CABLES = No Cables Installed
R = SLC Remote Port
S = RS232 Com1/2 Serial Port
TST = Setup for TST7600
BR = Mounting Bracket Installed
ACC = Extra port for accessories
Option 1
Option 2
Option 3
