D4204-EN Scale Link 2 Technical Manual 31
MENU 1.2 – TIME & DATE (JUMP LIST 12)
TIME F (D.A.N. 1201) Time Format
Select AM/PM or 24 HR time format.
TIME (D.A.N. 1202) Time
Enter the time. Use the LEFT/RIGHT arrows or FUNCTION key to select hours/minutes/seconds. Use the
UP/DOWN arrows or SELECT key to increment value.
DATE F (D.A.N. 1203) Date Format
Select one of the following date formats:
1 = mm/dd 5 = dd/mm/yy
2 = mm/dd/yy 6 = dd/mm/yyyy
3 = mm/dd/yyyy 7 = dd/MM/yy
4 = dd/mm 8 = dd/MM/yyyy
mm = 2-digit month (ex. January=01) – dd = 2-digit date (ex. 23) – yy = 2 digit year (ex. Year 2000=00)
yyyy = 4-digit year (ex. 2000) – MM = 2-character month (ex. January=JA)
DATE (D.A.N. 1204) Date
Enter the Date. Use the LEFT/RIGHT arrows or FUNCTION key to select hours/minutes/seconds. Use the
UP/DOWN arrows or SELECT key to increment value
DT CHK (D.A.N. 1205) Date Check
When enabled, adds verification of the system date at power up. An error will be displayed if the date is 2011 or before. The
operator will be prompted to press ON to set the time and date if an invalid date is found.
MENU 1.4 – REMOTE INPUTS (JUMP LIST 14)
RMINP1 (D.A.N. 1401) Remote Input 1 (Power port – Pin 4)
When line is pulled low, the following functions can be performed. Line may also be triggered with a high state;
jumper JU2 pins 2-3 and U17 installed.
NOTE: Not all features will be available depending on model.
PRESET Re-enters the last preset value entered.
SWITCH Displays an editable message for an ‘OPEN’ or ‘CLOSED’ condition on the remote input line. (See
RIMSG1, RISTAT, RITIME for additional options)
TARE Performs the TARE function and “zeroes” the display.
PRINT Performs a PRINT function.
